Main Technical Features
* The universal dyeing system for woven and knitted fabrics.
* This high temperature and high pressure rapid dyeing machine is specially suitable for crease sensitive woven fabrics of polyester, polyester blends, micro fibres, etc. The fabric velocity can be arbitrarily adjusted within the scope of 150-600m/min.
* On the basis of the optimal safety during running also at maximal speeds high load weights could be achieved even with light materials.
* Shortest dyeing times are possible based on high efficient heating-/cooling results and large quantities of circulated liquor.
Technical Details
* Adjustable winch drives allowing different fabric speeds at a programmed nozzle pressure
* Analog dosing: fully automated dosing of dyes and chemicals using time and curves (also possible under high temperature conditions)
* Available Specification:
Model | Fabric-Holding Capacity (KG) | Tube Quantity/ Slot Quantity | Installed Power (KW) | Dimension (Length X Width X Height) |
TH-VT 50 | 35-50 | 1/1 | 15.5 | 6600x1450x2450 |
TH-VT 100 | 70-100 | 1/1 | 19.5 | 7600x1450x2450 |
TH-VT - 1 | 175-250 | 1/1 | 23 | 11400x1600x2750 |
TH-VT - 2 | 350-500 | 2/2 | 43 | 11400x2500x2750 |
TH-VT - 4 | 700-1000 | 4/4 | 85.5 | 11400x4900x2750 |
* Available for operating temperatures up to 140°C.
* Bath ratio from 1:6-8
* 1-4 fabric tubes per machine available
